Specifications

Service:

Compatible liquids.

Wetted Materials:

Body: 316 SS, 316L SS; Bullet nose: PVC; Cable: Polyether polyurethane or ETFE; Seals: Fluoroelastomer.

Accuracy:

±0.25% FS.

Temperature Limit:

SBLT2: Polyurethane: 0 to 150°F (-18 to 66°C); ETFE: 0 to 200°F (-18 to 93°C); SBLTX -4 to 176°F (-20 to 80°C); Polyurethane: -4 to 149°F (-20 to 65°C).

Compensated Temperature Range:

SBLT2: 0 to 140°F (-18 to 60°C); SBLTX: 0 to 176°F (-18 to 80°C).

Thermal Effect:

±0.02% full scale/°F.

Pressure Limit:

2X FS.

Power Requirement:

SBLT2: 10 to 30 VDC (≤1000 ft (305 m) of cable); SBLTX: 10 to 28 VDC.

Output Signal:

4-20 mA DC, 2-wire.

Response Time:

50 ms.

Max. Loop Resistance:

900 Ω at 30 VDC.

Electrical Connections:

Wire pigtail.

Mounting Orientation:

Suspended in tank below level being measured.

Electrical Protection:

SBLT2: Lightning and surge protection; SBLTX: None.

Weight:

2.2 lb (1.0 kg).

Compliance:

SBLT2: CE; SBLTX: CE, cULus intrinsically safe for Class I, Div. 1, Groups A, B, C, D; Class II, Div. 1, Groups E, F, G; Class III Div. 1; ATEX: II 1 G Ex ia IIC T4 Ga and II 1 D Ex ia IIIC T135C Da (according to control drawing 001833-43)*.

Up to 275' (83.8 m) for ETFE cable; Up to 470' (143.3 m) for polyurethane cable.
