Dwyer RHPX-3SDA0-00 – Cảm biến độ ẩm và nhiệt độ gắn ống gió

Mã hàng: RHPX-3SDA0-00

Xuất xứ: Dwyer

Chiết khấu liên hệ: sales@getvn.vn hoặc 0943530440

Mã hàng: RHPX-3SDA0-00

Đánh giá sản phẩm

Liên Hệ

Humidity Measurement Range:: 0 % to 100 % humidity.
Temperature Measurement Range:: -40 °C to 60 °C (-40 °F to 140 °F).
Humidity Sensor Accuracy:: Model specific, ±2 % or ±3 %, at 10 % - 90 % RH and 25 °C (77 °F).
Temperature Sensor Accuracy:: Thermistor: ±0.2 °C at 25 °C (±0.36 °F at 77 °F); RTD: DIN class B ±0.3 °C at 0 °C (±0.54 °F at 32 °F); solid state band gap: ±0.5 °C at 25 °C (±0.9 °F at 77 °C).
Resolution:: Relative humidity: 0.1%; temperature: 0.1°F/°C; absolute humidity: 0.1 g/m3).
Humidity Analog Output:: 4-20 mA or 0-5 V dc, 0-10 V dc at 5 mA max, field selectable.
Active Temperature Analog Output:: 4-20 mA or 0-5 V dc, 0-10 V dc at 5 mA max, field selectable.
Passive Temperature sensors:: Types II and III: Solid state band gap; Curves A, B, and F: Thermistor; Curves D and E: Platinum RTD DIN 385, Balco 1K (model specific, not available with remote humidity sensor) model dependent.
Network Communication:: BACnet MS/TP protocol or Modbus® RTU.
Supported BAUD Rates:: 9600, 19200, 38400, 57600, 76800, 115200.
Termination Load:: 120 ohm (communicating models only).
Operating Temperature Range:: -40°C to 60°C (-40°F to 140°F); With LCD: -20°C to 60°C (-4°F to 140°F).
Power Requirements:: Communications model: (14 to 35) V dc, (10 to 32) V ac; Analog model: 4-20 mA: (10 to 35) V dc; Voltage output: (15 to 35) V dc or (15 to 29) V ac.
Wiring Connection:: Removable terminal block.
Conduit Connection:: 1/4 ? or 1/2 ? NPS.
Humidity Sensor:: Capacitive polymer.
Enclosure Material:: UL 94 V-0.
Enclosure Rating:: IP66.
Optional Display:: Two (2) lines of alphanumeric characters with eight (8) characters per line.
Weight: Duct:: 198.4 g (0.44 lb); wall mount: 170 g (0.38 lb); large housing: 340.2 g (0.75 lb); large housing with rad shield: 1247.4 g (2.75 lb).
Storage Temperature:: -40°C to 70°C (-40°F to 158°F); With LCD: -30°C to 70°C (-22°F to 158°F).
Additional calculations:: Absolute humidity: (0 to 50) g/m3 or (0 to 3000) lb/mmcf; dew point -75 °C to 60 °C (-102 °F to 140 °F); enthalpy (-40 to 411) kj/kg or (-17 to 177) Btu/lb.
Compliance:: BTL, CE, UL 2043*, UL-60335-2-40**.
: * UL 2043 compliance limited to models:
RHPX-XS(B,S,W) Wall Mount
RHPX-XS(D,E)-XX-X Plastic Probe Duct Mount without LCD
RHPX-XS(F,G)-XX-X SSTL Duct Mount with LCD
RHPX-XL(B,S,W) Large Wall Mount without LCD
RHPX-XL(H) Large Wall Mount without LCD & Solar Radiation Shield
** Meets UL-60335-2 clause 30.103DV.1 through UL2043 compliance
